Deploying a SQL DB with Azure Pipelines

Normally when I work with SQL Azure I handle DB schema changes with Entity Framework migrations. However if you using Azure Functions rather than Web Jobs it seems there's a number of issues with this and I could not find a decent guide which resulted in a working solution.

Migrations isn't the only way to release a DB change though. SQL Server Database projects have existed for a long time and are a perfectly good way of automating a DB change. My preference to use EF Migrations really comes from a place of not wanting to have an EF model and a separate table scheme when they're essentially a duplicate of each other.

Trying to find out how to deploy this through Azure Devops Pipelines however was far harder than I expected (my expectation was about 5 mins). A lot of guides weren't very good and virtually all of them start with Click new pipeline, then select Use the classic editor. WAIT Classic Editor on an article written 3 months ago!?!?! Excuse me while I search for a solution slightly more up to date.

Creating a dacpac file

High level the solution solution is to have a SQL Server Database project, use an Azure Pipeline to compile that to a dacpac file. Then use a release pipeline to deploy that to the SQL Azure DB.

I'm not going to go into any details about how you create a SQL Server Database project, its relatively straightforward, but the one thing to be aware of is the project needs to have a target platform of Microsoft Azure SQL Database otherwise you'll get a compatibility error when you try to deploy.

Building a SQL Server Database project in Azure Devops

To build a dacpac file create a new pipeline in Azure Devops (the yaml kind), select your repo and get yourself a blank configuration file. Also at this point make sure your code is actually in the repo!

The configuration I used looks like this; I've included notes in the code to explain what's going on.

# The branch you want to trigger a build
trigger:
- master

pool:
vmImage: "windows-latest"

variables:
configuration: release
platform: "any cpu"
solutionPath: # Add the path to your Visual Studio solution file here

steps:
# Doing a Visual Studio build of your solution will trigger the dacpac file to be created
# if you have more projects in your solution (which you probably will) you may get an error here
# as we haven't restored any nuget packages etc. For just a SQL DB project, this should work
- task: VSBuild@1
  displayName: Build solution
  inputs:
    solution: $(solutionPath)
    platform: $(platform)
    configuration: $(configuration)
    clean: true

# When the dacpac is built it will be in the projects bin/configuation folder
# to get into an artifact (probably with some other things you want to publish like an Azure function)
# we need to move it somewhere else. This will move it to a folder called drop
- task: CopyFiles@2
  displayName: Copy DACPAC
  inputs:
    SourceFolder: "$(Build.SourcesDirectory)/MyProject.Database/bin/$(configuration)"
    Contents: "*.dacpac"
    TargetFolder: "$(Build.ArtifactStagingDirectory)/drop"

# Published the contents of the drop folder into an artifact
- task: PublishBuildArtifacts@1
  displayName: "Publish artifact"
  inputs:
    PathtoPublish: "$(Build.ArtifactStagingDirectory)/drop"
    ArtifactName: # Artifact name goes here
    publishLocation: container

Releasing to SQL Azure

Once the pipeline has run you should have an artifact coming out of it that contains the dacpac file.

To deploy the dacpac to SQL Azure you need to create a release pipeline. You can do this within the build pipeline, but personally I think builds and releases are different things and should therefore be kept separate. Particularly as releases should be promoted through environments.

Go to the releases section in Azure Devops and click New and then New release pipeline.

There is no template for this kind of release, so choose Empty job on the next screen that appears.

On the left you will be able to select the artifact getting built from your pipeline.

Then from the Tasks drop down select Stage 1. Stages can represent the different environments your build will be deployed to, so you may want to rename this something like Dev or Production.

On Agent Job click the plus button to add a task to the agent job. Search for dacpac and click the Add button on Azure SQL Database deployment.

Complete the fields to configure which DB it will be deployed to (as shown in the picture but with your details).

And that's it. You can now run the pipelines and your SQL Project will be deployed to SQL Azure.

Some other tips

On the Azure SQL Database deployment task there is a property called Additional SqlPackage.exe Arguments this can be used to specify things like should loss of data be allows. You can find the list of these at this url https://docs.microsoft.com/en-us/sql/tools/sqlpackage/sqlpackage?view=sql-server-ver15#properties

If you are deploying to multiple environments you will want to use variables for the server details rather than having them on the actual task. This will make it easier to clone the stages and have all connections details configured in one place.

Logging with .net core and Application Insights

When you start builing serverless applications like Azure functions or Azure web jobs, one of the first things you will need to contend with is logging.

Traditionally logging was simply achieved by appending rows to a text file that got stored on the same server your application was running on. Tools like log4net made this simpler by bringing some structure to the proces and providing functionality like automatic time stamps, log levels and the ability to configure what logs should actually get written out.

With a serverless application though, writing to the hard disk is a big no no. You have no guarantee how long that server will exist for and when your application moves, that data will be lost. In a world where you might want to scale up and down, having logs split between servers is also hard to retrieve when an error does happen.

.net core

The first bit of good news is that .net core supports a logging API. Here I am configuring it in a web job to output logs to the console and to Application insights. This is part of the host builder config in the program.cs file.

//3. LOGGING function execution :
//3 a) for LOCAL - Set up console logging for high-throughput production scenarios.
hostBuilder.ConfigureLogging((context, b) =>
{
  b.AddConsole();

  // If the key exists in appsettings.json, use it to enable Application Insights rather than console logging.
  //3 b) PROD - When the project runs in Azure, you can't monitor function execution by viewing console output (3 a).
  // -The recommended monitoring solution is Application Insights. For more information, see Monitor Azure Functions.
  // -Make sure you have an App Service app and an Application Insights instance to work with.
  //-Configure the App Service app to use the Application Insights instance and the storage account that you created earlier.
  //-Set up the project for logging to Application Insights.
  string instrumentationKey = context.Configuration["APPINSIGHTS_INSTRUMENTATIONKEY"];
  if (!string.IsNullOrEmpty(instrumentationKey))
  {
      b.AddApplicationInsights(o => o.InstrumentationKey = instrumentationKey);
  }
});

Microsofts documentation on logging in .NET Core and ASP.NET can be found here.

Creating a log in your code is then as simple as using dependency injection on your classes to inject an instance of ILogger and then using it's functions to create a log.

public class MyClass
{
  private readonly ILogger logger;

  public MyClass(ILogger logger)
  {
      this.logger = logger;
  }

  public void Foo()
  {
      try
      {
          // Logging information
          logger.LogInformation("Foo called");
      }
      catch (Exception ex)
      {
          // Logging an error
          logger.LogError(ex, "Something went wrong");
      }
  }
}

Application Insights

When your application is running in Azure, Application Insights is where all your logs will live.

What's great about App Insights is it will give you the ability to write queries against all your logs.

So for instance if I wanted to find all the logs for an import function starting, I can write a filter for messages containing "Import function started".

Queries can also be saved or pinned to a dashboard if they are a query you need to run frequently.

For all regular logs your application makes you need to query the traces. What can be confusing with this though is the errors.

With the code above I had a try catch block and in the catch block I called logger.LogError(ex, "Something went wrong"); so in my logs I expect to see the message and as I passed an exception I also expect to see an exception. But if we look at this example from application insights you will see an error in the traces log but no strack trace or anything else from the exception.

This is just the start of the functionality that Application Insights provides, but if your just starting out, hopefully this is a good indication not only of how easy it is to add logging to your application, but also how much added value App Insights can offer over just having text files.

What are automated deployments and why do I need them?

When your working on a new website build as either the marketer responsible for the site or the project manager overseeing it’s build, some of the most frustrating tasks to be using up your budget can originate from the IT team and come under the category of setup.

They can suck days even weeks from a project but offer no visible features or benefit to the end user, worse still they often need to come at the start of a project which for people wanting to see a design turn into a webpage just feels like a delay and lack of progress.

Manual Deployments

So, what are automated deployments and why are they worth it? Well first let’s examine what a deployment is to begin with.

When a change or new feature is ready to be built for a site, it will have been turned into a specification and handed over to a development team to build. The developers will then write some code and test it on their local machines, they may even demo it to someone else. At some point though, that work needs to get from their machine to the server(s) it runs on so that other people like QA can see it without using the devs machine. Typically, there will be 3 server environments set up for a website:

  1. Dev / Test – An environment used by the developers and QA to build, test and refactor new features and fixes.
  2. UAT / Staging – An environment used by the website owners / stakeholders that the features have been deployed to for review and approval before they are deployed into production.
  3. Production – The live website that is accessible over the internet.

In a manual deployment setup, the developer is responsible for copying the website into each of the environments. This will generally involve:

  1. Getting the version of code to be deployed from source control.
  2. Publishing a build of the site locally (some languages need to be compiled into machine code, and most modern websites will run a task on the CSS and JavaScript to obfuscate and reduce the file size).
  3. Login to databases and run any scripts to update the database.
  4. Login to the web servers using something like a remote desktop client.
  5. Copy and Paste the new files onto the server.
  6. Make some sort of record that the deployment has been done and what it included.

As you can probably guess each of these steps is prone to human error; What if the developer gets the wrong version from source control? What if they overwrite the wrong folder? What if they miss the database changes? What if they don’t record the deployment, how can we be sure what version is on an environment?

Not only that but it’s also a lengthy task for someone to do. Some parts are just waiting for a code publish to complete or a file copy to finish. For the odd production deploy with a decent checklist this might not be so bad, but for iterating work into QA this can not only make QA fails for minor things really costly to fix, but also result in bundling more and more changes together to cut down the number of releases which then reduces the flow of work feeding into QA and slows the pace at which features can be developed and released.

A Better Way

Now we understand the issues, we certainly don’t want that as a cost throughout the lifetime of our site, so how do we avoid it?

Well, automated deployments quite simply take all these manual steps, automated them with a few bonuses on top. By doing this we remove all the elements of human error and are left with consistent results each time.

There’s two parts to an automated pipeline, the first is build and the second is release.

The build part relates to the first 2 steps of our manual process. We need to get the code from source control and then publish it. Once we’ve done this, we are left with a build that we can assign a release number to. By automating it we’ve also ensured that the build happens the same way each time rather than any differences between developers’ machines being. At this point we can also start detecting build failures and include some automated testing to pick up on errors before even involving QA.

The release part relates to the remaining steps of the manual process. First of all the process of copying files and running scripts now becomes one large script that won’t miss a step and in addition to that, now we have build numbers we can see which build is on each environment and only promote the one we want to the next environment. Because we’re promoting builds rather than doing the whole build process again, we’re also ensuring that the build going to production is the exact same thing that was tested on QA and then reviewed on UAT. With some clever integrations with things like GitHub and Jira we can also automated release notes to say what was included in each of the releases.

Degrees of Automation

It worth noting at this point that there are different degrees of automation and this will greatly affect the cost of setup.

As well as automating the deploy of code, we could also automate the entire server setup through the use or ARM templates in Azure. Different levels of automated testing can be implemented from very low code coverage to very high; a test could even be what the level of code coverage is.

Automation could also extend to include load balancers for green / blue deployments where zero downtime of the site is achieved by using multiple production servers and switching between them while files are being copied.

Is this the CI and CD thing I’ve heard about?

Two terms I deliberately haven’t used in this article is Continuous Integration (CI) and Continuous Delivery (CD) and that’s because although automated deployments forms part of achieving them they are not the same thing and it’s worth knowing how they differ.

Continuous Integration related to the build part of the automated setup and aims to deal with issues arising from multiple developers working on a project. When more than one developer works on a copy of a website locally, both sets are changing in different way to what is contained within source control. The longer this goes on for the bigger the differences get and the harder it will become to merge again. Continuous Integration advocates shortening the gaps between merges to as shorter time as possible, potentially multiple time per day. By having automated tools in place to run a build whenever this happens, issues can be identified as early as possible.

Continuous Delivery relates more to the release aspect of the automated setup and is an aim to be constantly delivering / deploying updates to a solution as fast as possible. By doing this, deployments become trivial and smaller updates are delivered at a much faster pace rather that being queued for one big release. Automation helps make this a reality by removing many of the manual time consuming tasks that are repetitive.
